High Quality Golden Supplier SMD Switch Membrane Wireless Touch Membrane Switch

Introducing, the Soushine’s High Quality Golden Supplier SMD Switch Membrane Wireless Touch Membrane Switch - the perfect solution for all your touch-sensitive switching needs. This innovative product boasts a sleek and modern design, providing both functionality and style.

With its advanced SMD technology, this membrane switch offers high precision and reliability, ensuring smooth and effortless operation every time. The wireless feature allows for easy installation and flexibility in placement, making it ideal for a wide range of applications.

The touch-sensitive membrane provides a responsive and intuitive user experience, allowing you to effortlessly control your devices with just a light touch. The switch is designed to withstand frequent use and is built to last, making it a durable and long-lasting solution for your switching needs.

The Soushine’s High Quality Golden Supplier SMD Switch Membrane Wireless Touch Membrane Switch is a versatile product that can be used in a variety of settings, from home automation to industrial applications. Its high-quality construction and precise engineering make it a reliable choice for any project.

Whether you are looking to upgrade your existing switches or are starting a new project from scratch, the Soushine’s High Quality Golden Supplier SMD Switch Membrane Wireless Touch Membrane Switch is the perfect choice. Trust in the Soushine brand for high-quality products that exceed expectations.

The Soushine’s High Quality Golden Supplier SMD Switch Membrane Wireless Touch Membrane Switch is a top-of-the-line solution for all your switching needs. With its advanced technology, sleek design, and reliable performance, this product is sure to make a lasting impression. Upgrade to the Soushine membrane switch today and experience the difference for yourself.

Choose quality, choose reliability, choose Soushine

Wholesale Price Matrix Membrane Smart Switch With Ied Waterproof  Panel Membrane Switch Keyboard

Get a Free Quotation via Us >>> Go

Products Description

Membrane Switch With aluminum back support
Six layers: graphic overlay
Total thickness rang from 0.6-0.8mm

Overlay Material	PET, PC, EBG180, EGA180, Glass, Acrylic
Artwork Format	CorelDraw, AI, CAD, CDR, PDF
Color	Pantone and RALcolor matching system
Button options	Tactile: metal dome, poly dome, silicone button
		Non-tactile: flat button, printed silver spot on the circuit
Connector	ZIF connector: 0.5mm, 1.0mm, 1.25mm pitch
		Female connector with 2.54mmpitch
Circuit option	Silver printed conductive inks, FPC, PCB
Printing	Screen printing, Semi-Auto matic printing, Automatic Printing
Window	Transparent, translucent red/black/white etc window
Surface	Glossy surface or matte surface
Rear Adhesive	3M467,3M468, 3M9448MP, 3M300LSE, 3M93420 etc
Certificate	ISO9001、RoHS、CE、TUV

Get a Free Quotation via Us >>> Go

Circuit level	35V (DC), 100mA, 1W
Contact resistance	10 Ω~ 500 Ω (varies according to the length and material of outgoing
Insulation impedance	100M Ω 100V
Dielectric withstand voltage	No breakdown or flashover after 250V RMS (50-60Hz 1min) test
Contact jitter time	≤5ms
Service life	Plane type ≥5 million times
Touch type	≥1 million times
Operating pressure	Plane type 57~ 284g - 2 ~ 10oz
Tactile type	170-397g - 6-14oz
Switch stroke	Plane type 0.1~ 0.5mm

1、Cheap and cost-effective

2、Adjustable touch of buttons

3、Easy to clean and lightweight

4、The button can be used for glue dripping process

.

1、High temperature resistance

2. Waterproof and UV resistant

3. Long service life, good pressure resistance and anti breakdown

1、Adjustable touch of buttons

2、High lifespan

3、Laser with backlight effect

4、Imported raw materials and accessories

Recommend products

Company strength

About us

Established in 2008, Dongguan soushine Industrial Co., Ltd. is a technology company integrating design, research and development, production and sales. It covers an area of 4000 square meters and has two production workshops. After more than 20 years of development, we have a strong R & D technology and production capacity, the main products are: film switch, touch switch, film pressure sensor, graphic cover, panel and so on. These products are widely used in communication, industrial control, medical equipment, automobiles, instruments, smart home and toys, automatic control systems and other high-tech fields. Our partners are Haier, Midea, Huawei, Panasonic and other well-known enterprises. The company has more than 100 employees, more than 300 equipment, 10 production lines. And passed ISO9001:2015, RoHS, ZHB environmental system certification, is a national high-tech enterprise

FAQ

Q1. What information will I have to provide for price

A:To offer the exact price, we hope customers could inform us the material, specification as thickness, size, with adhesive or not, how many colors for printings, contact details, quantity required, Size and Shape with artwork files

Q2. What is the production time
(1) Custom sample: About 7 days.
(2) Mass production: About 2--3 weeks

Q3. Can you do the design for us
Yes. There ate many professional engineer having rich experience in graphic overlays& circuit designing
Just let us know your ideas and we will help to carry out your ideas into perfect products
If you send me your samples, we will design the drawings based on the samples and can revise the graphic of the face

Q4. How about your delivery time
A: After the engineering drawing is confirmed, the sample will be completed in 5 days, and after the sample is confirmed, the mass goods will be completed in 10 days. The specific delivery time depends on the items and the quantity of your order
