Factory Directly Offer Membrane Keyboard

Are you in need of a reliable and high-quality membrane keyboard for your computer? Look no further than the Soushine brand, which offers factory-direct pricing on top-notch keyboards that are perfect for any user.

Soushine’s membrane keyboards are designed to provide a comfortable typing experience, with soft and responsive keys that are easy to press and quiet to use. The sleek and modern design of these keyboards will complement any desktop setup, whether at home or in the office.

One of the main advantages of membrane keyboards is their durability. The keys are protected by a thin, flexible membrane that helps prevent dust and debris from getting inside and causing damage. This means that your Soushine keyboard will stay in great condition for years to come, even with heavy daily use.

In addition to their durability, Soushine’s membrane keyboards are also incredibly easy to clean. The smooth surface of the keys allows for quick and simple wiping with a damp cloth, keeping your keyboard looking brand new at all times.

Another advantage of membrane keyboards is their affordable price point. By offering factory-direct pricing, Soushine can provide top-of-the-line keyboards at a fraction of the cost of other brands. This means that you can enjoy all the benefits of a high-quality membrane keyboard without breaking the bank.

Whether you are a casual computer user or a professional who spends hours typing every day, a Soushine’s membrane keyboard is the perfect choice. With its comfortable design, durable construction, and affordable price, this keyboard is sure to become your go-to choice for all your typing needs.

Don't settle for a subpar keyboard that will wear out quickly and leave you frustrated. Upgrade to a Soushine’s membrane keyboard today and experience the difference that a high-quality keyboard can make. Shop now and take advantage of factory-direct pricing on this top-notch product

Wholesale Price Matrix Membrane Smart Switch With Ied Waterproof  Panel Membrane Switch Keyboard

Get a Free Quotation via Us >>> Go

Products Description

Membrane Switch With aluminum back support
Six layers:
graphic overlay
Total thickness rang from 0.6-0.8mm

Overlay Material	PET, PC, EBG180, EGA180, Glass, Acrylic
Artwork Format	CorelDraw, AI, CAD, CDR, PDF
Color	Pantone and RALcolor matching system
Button options	Tactile: metal dome, poly dome, silicone button
		Non-tactile: flat button, printed silver spot on the circuit
Connector	ZIF connector: 0.5mm, 1.0mm, 1.25mm pitch
		Female connector with 2.54mmpitch
Circuit option	Silver printed conductive inks, FPC, PCB
Printing	Screen printing, Semi-Auto matic printing, Automatic Printing
Window	Transparent, translucent red/black/white etc window
Surface	Glossy surface or matte surface
Rear Adhesive	3M467,3M468, 3M9448MP, 3M300LSE, 3M93420 etc
Certificate	ISO9001、RoHS、CE、TUV

Get a Free Quotation via Us >>> Go

Circuit level	35V (DC), 100mA, 1W
Contact resistance	10 Ω~ 500 Ω - varies according to the length and material of outgoing
Insulation impedance	100M Ω 100V
Dielectric withstand voltage	No breakdown or flashover after 250V RMS (50-60Hz 1min) test
Contact jitter time	≤5ms
Service life	Plane type ≥5 million times
Touch type	≥1 million times
Operating pressure	Plane type 57~ 284g - 2 ~ 10oz
Tactile type	170-397g - 6-14oz
Switch stroke	Plane type 0.1~ 0.5mm

1、Cheap and cost-effective

2、Adjustable touch of buttons

3、Easy to clean and lightweight

4、The button can be used for glue dripping process

.

1、High temperature resistance

2. Waterproof and UV resistant

3. Long service life, good pressure resistance and anti breakdown

1、Adjustable touch of buttons

2、High lifespan

3、Laser with backlight effect

4、Imported raw materials and accessories

Recommend products

Company strength

About us

Established in 2008, Dongguan soushine Industrial Co., Ltd. is a technology company integrating design, research and development, production and sales. It covers an area of 4000 square meters and has two production workshops. After more than 20 years of development, we have a strong R & D technology and production capacity, the main products are: film switch, touch switch, film pressure sensor, graphic cover, panel and so on. These products are widely used in communication, industrial control, medical equipment, automobiles, instruments, smart home and toys, automatic control systems and other high-tech fields. Our partners are Haier, Midea, Huawei, Panasonic and other well-known enterprises. The company has more than 100 employees, more than 300 equipment, 10 production lines. And passed ISO9001:2015, RoHS, ZHB environmental system certification, is a national high-tech enterprise

FAQ

Q1. What information will I have to provide for price

A:To offer the exact price, we hope customers could inform us the material, specification as thickness, size, with adhesive or not, how many colors for printings, contact details, quantity required, Size and Shape with artwork files

Q2. What is the production time

(1) Custom sample: About 7 days

(2) Mass production: About 2--3 weeks

Q3. Can you do the design for us
Yes. There ate many professional engineer having rich experience in graphic overlays& circuit designing

Just let us know your ideas and we will help to carry out your ideas into perfect products. If you send me your samples, we will design the drawings based on the samples and can revise the graphic of the face

Q4. How about your delivery time
A: After the engineering drawing is confirmed, the sample will be completed in 5 days, and after the sample is confirmed, the mass goods will be completed in 10 days. The specific delivery time depends on the items and the quantity of your order

Q5: How to control quality

A:

(1) We process the products strictly based on the raw material list.

(2) Our many engineer own many years experience and are very responsible.
(3) Warranty period is one year. If you find some products is bad, you can tell us, we will give you solutions

Q6: What's terms of payment for custom a new item
A: The mold cost should pay 100% in advanceThe bulk order we can accept 50% deposit, 50% before shipping and pay through Alibaba assurance order, T/T

Q7: Where is your factory, can I visit
A: We located in Dongguang, China. And welcome to visit any time.
